ADR233B
option.
Ph Differential
Hrm BLK Criteria
Disabled
Editable Setting
Password protected window for “Hrm BLK Criteria” setting
i.e. Disabled / Blocked / Restrain
Press the Minus / Down arrow key (- /) to move to the next
option.
Ph Differential
5th Hrm Diff BLK
Disabled
Editable Setting
Password protected window for “5th Hrm Diff BLK” setting
i.e. Disabled / Enabled.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTIONS
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

8.4.11.3.2 Ph Differential (If Enabled)
PROTECTIONS
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
