Ashida ADR233B - Group 1 - Menu List

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 306 of 479
ADR233B
SYSTEM CONFIG
PROTECTIONS
CLEAR RECORDS
OUTPUT & LED TEST

8.4.11 Group 1
8.4.11.1 Group 1 – Menu List
PROTECTIONS
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
Equipments Data
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Equipment Data.
Password protected window for “Equipment Data” setting
i.e. W1 Connection, W1 Grounding, W1 Nominal Range, W1
Nominal, MVA Rating, Vector Group, W2 Connection, W2
Grounding, W2 Nominal Range, W2 Nominal, W1 Match
Factor, W2 Match Factor and REF Match Factor.
Press the Minus / Down arrow key (- /) to move to the next
option.
Ph Differential
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Ph Differential.
Password protected window for “Ph Differential” setting i.e.
Ph Differential Disabled/Enabled, (Is>1, Slope1, Is>2, Slope2,
tIs>, IHs>1, IHs>2) Hrm BLK Criteria, Hrm BLK Mode (2nd
Hrm Threshold and 4th Hrm Diff Threshold) (Cross blocking &
t Cross blocking) 5th Hrm Diff BLK (5H Diff Threshold & t 5th
Hrm)
Press the Minus / Down arrow key (- /) to move to the next
option.
