Under Voltage SET
V<
10 %
Range 5 – 95%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the V< can be set.
The setting range is from 5 to 95% in step of 1%.
Press the Minus / Down arrow key (- /) to move to the next
option.
Under Voltage SET
tV< Delay
0.1 s
Range 0 – 99s
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the tV< Delay can be set.
The setting range is from 0 to 99s in step of 0.1s.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

8.4.11.10 Over Voltage
8.4.11.10.1 To Set – Over Voltage (If Disabled)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
