Ashida ADR233B - Sequence OC (if Definite Time Is Selected)

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 364 of 479
ADR233B
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Note: The W1 Sequence OC settings of Seq.I>2 Enable and Seq.I>3 Enable for all IEEE / US Curves
is similar to Sequence OC setting of Seq.I>1 Enable.
Note: The W1 Sequence OC settings of W2 Sequence OC is similar to W1 Sequence OC.
8.4.11.8.4 Sequence OC (If Definite Time is selected)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
Phase OC
Ground OC
Residual OC
Sequence OC

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Sequence OC.
Press the Right arrow key () to move to the next option.
Sequence OC
W1 Sequence OC

W2 Sequence OC
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select W1 Sequence OC.
Password protected window for “W1 Sequence OC” setting
i.e. Seq. I>1 Enable, Seq. I>2 Enable and Seq. I>3 Enable
can be set as Disabled / -Seq / +Seq.
Press the Right arrow key () to move to the next option.
