Ashida ADR233B - V;Hz Protection (if Enabled)

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 373 of 479
ADR233B
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

8.4.11.11.2 V/Hz Protection (If Enabled)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
Sequence OC
Under Voltage
Over Voltage
V/Hz Protection

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select V/Hz Protection.
Password protected window for “V/Hz Protection” setting i.e.
V/Hz – 1 Protection, V/Hz – 2 Protection, V/Hz – 3 Protection,
V/Hz – 4 Protection, V/Hz – 5 Protection, V/Hz – 6 Protection
and can be set as Disabled/Enabled
Press the Right arrow key () to move to the next option.
V/Hz Protection
V/Hz – 1 Protection

Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select V/Hz – 1 Protection.
Password protected window for “V/Hz – 1 Protection” setting
i.e. can be set as Disabled / Enabled.
