Ashida ADR233B - To Set - under Voltage (if Disabled); Under Voltage

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 367 of 479
ADR233B
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Note : The W1 Sequence OC settings of Seq.I>2 Enable and Seq.I>3 Enable for Definite Time Curve is
similar to W1 Sequence OC setting of Seq.I>1 Enable.
Note : The Sequence OC settings of W2 Sequence OC is similar to W1 Sequence OC.
8.4.11.9 Under Voltage
8.4.11.9.1 To Set – Under Voltage (If Disabled)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
Ground OC
Residual OC
Sequence OC
Under Voltage

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Under Voltage.
Press the Right arrow key () to move to the next option.
Under Voltage
Under Voltage SET

Disabled
Editable Setting
Password protected window for “Under Voltage SET” can be
set i.e. Disabled / Enabled.
Note: When set as Disabled.
Press the Right arrow key () to move to the next option.
