Ashida ADR233B - Status; To View - Status

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 289 of 479
ADR233B
8.4.6.2 Status
8.4.6.2.1 To View – Status
MEASURMENT
GLOBAL
CB CONTOL
REPORTING

This menu is to view “Reporting” i.e. Event, Status, Fault
Record, Error Log, CB Data and Alarm Record.
Press the Right arrow key () to move to the next option.
Status

By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select “Status”
Press the Right arrow key () to move to the next option.
Applicable for Modular Relay
H In : 87654321
00000000
I In : 87654321
00000000
This window shows actual status of Digital Inputs
Press the Minus / Down arrow key (- /) to move to the next
option.
N In : 87654321
00000000
O In : 87654321
00000000
This window shows actual status of Digital Inputs (available in
M19)
Press the Minus / Down arrow key (- /) to move to the next
option.
J Out : 87654321
00000000
K Out : 87654321
00000000
This window shows actual status of Digital Inputs
Press the Minus / Down arrow key (- /) to move to the next
option.
L Out : 87654321
00000000
M Out : 87654321
00000000
This window shows actual status of Digital Output (available
in M19)
Press the Right arrow key () to move to the Main Menu.
Applicable for Enhance Relay
H In : 87654321
00000000
I In : 21
00
This window shows actual status of Digital Inputs
Press the Minus / Down arrow key (- /) to move to the next
option.
