9 L9 User Programmable Dual Colour LED.
10 L10 User Programmable Dual Colour LED.
11 L11 User Programmable Dual Colour LED.
12 L12 User Programmable Dual Colour LED.
13 L13 User Programmable Dual Colour LED.
14 L14 User Programmable Dual Colour LED.
15 L15 User Programmable Dual Colour LED.
16 L16 User Programmable Dual Colour LED.
8.2.4 Communication ports
1. USB port is provided at front side. It is used to retrieve Disturbance Records (last 10 faults);
faults waveforms and parameterization using Relay Talk software.
2. RS485 (2 wire) port is provided at rear side and it is used for SCADA communication.
3. 2 no’s of Ethernet Port (RJ45/FO) is provided at rear side and it is used for SCADA
communication.
4. Relay is provided with open protocols like IEC60870-5-103, MOBUS and IEC61850 for
external communication.
8.3 EDITING PASSWORD / NEW PASSWORD and SAVING SETTINGS
MEASURMENTS
GLOBAL

CB CONTOL
REPORTING
This is default window showing the Main Menu.
Step 1 : By using Plus / Up arrow Key (+ /) or Minus / Down
arrow key (- /) scroll the Main Menu / Group and select
GLOBAL setting.
Step 2 : Press the right arrow key () the relay will display
the next option.
General Settings

Setting Group
PORT F
PORT 1
Step 3 : By using Plus / Up arrow Key (+ /) or Minus / Down
arrow key (- /) scroll the Main Menu / Group and select
General settings.
Step 4 : Press the right arrow key () the relay will display
the next option.
General Settings
Password
****
This window will be displayed
Step 5 : Press the Edit Key to activate the settings
