Ashida ADR233B - Residual OC (if Definite Time Is Selected)

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 353 of 479
ADR233B
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Note: The W1 Residual OC settings of 3Io>2 Enable and 3Io>3 Enable for all IEEE / US Curves is
similar to W1 Residual OC setting of IE>1 Enable.
Note: The Residual OC settings of W2 Residual OC is similar to W1 Residual OC.
8.4.11.7.4 Residual OC (If Definite Time is selected)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
REF
Phase OC
Ground OC
Residual OC

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Residual OC.
Press the Right arrow key () to move to the next option.
Residual OC
W1 Residual OC

W2 Residual OC
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select W1 Residual OC.
Password protected window for “W1 Residual OC” setting
i.e. 3Io>1 Enable, 3Io>2 Enable and 3Io>3 Enable can be set
as Disabled/Enabled.
Press the Right arrow key () to move to the next option.
