Ashida ADR233B - IRIG Port (Optional)

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 273 of 479
ADR233B
option.
PORT R
Baud Rate
57600
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Baud Rate can be set. i.e. 9600 / 19200 /
38400 / 57600.
Press the Minus / Down arrow key (- /) to move to the next
option.
PORT R
Parity
Even
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Parity can be set i.e. None / Even / Odd.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
MEASURMENTS
GLOBAL

CB CONTOL
REPORTING
8.4.4.7 IRIG Port (Optional)
MEASURMENTS
GLOBAL

CB CONTOL
REPORTING
Password protected window for “Global” setting. i.e. General
Settings, Setting Group, Port F, Port 1, PORT R , IRIG Port,
Disturbance, Display Contrast and Date and Time.
Press the Right arrow key () to move to the next option.
