Note: The settings for Breaker Failure i.e. W2 50 BF is similar to W1 50 BF Settings.
8.4.11.12.2 To Set – W1 50 BF (If Enabled)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
Under Voltage
Over Voltage
V/Hz Protection
Breaker Failure

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Breaker Failure.
Press the Right arrow key () to move to the next option.
Breaker Failure
W1 50BF

W2 50BF
Editable Setting
Password protected settings for “Breaker Failure” i.e. W1
50BF and W2 50BF.
Press the Right arrow key () to move to the next option.
W1 50 BF
W1_50BF Enabled
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired W1_50BF Enable can be set i.e.
Disabled / Enabled.
Note: When set as Enabled.
Press the Right arrow key () to move to the next option.
