ADR233B
W1 50BF
50BF Delay
0.10 s
Range 0 – 50s
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 50BF Delay settings can be set.
The setting range is from 0 to 50.00 s in step of 0.01 s.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 50BF
50BF Reset
CB Open + I<
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 50BF Reset can be set i.e. I< / CB
Open+I< / Prot Reset+I< / CB Open.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 50BF
50BF_IP<
1.00 A
Range 0.05 – 3.20A
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 50BF_IP< can be set.
The setting range is from 0.05 to 3.20A in step of 0.01A.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 50BF
Remove IP> P
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Remove IP> P can be set i.e. Disabled /
Enabled
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
