Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
MEASURMENTS
GLOBAL

CB CONTOL
REPORTING
8.4.4.6 PORT R
MEASURMENTS
GLOBAL

CB CONTOL
REPORTING
Password protected window for “Global” setting. i.e. General
Settings, Setting Group, Port F, Port 1, PORT R , IRIG Port,
Disturbance, Display Contrast and Date and Time.
Press the Right arrow key () to move to the next option.
Settings Group
PORT F
PORT 1
PORT R

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select PORT R.
Password protected window for “PORT R” setting i.e. Unit ID,
Baud Rate and Parity.
Press the Right arrow key () to move to the next option.
PORT R
Unit ID
1
Range 1 – 247
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Unit ID address can be set. The setting
range is from 001 to 247 in step of 001, which means total
247 devices can be connected to single computer. These
settings are required to communicate with the SCADA
computer.
Press the Minus / Down arrow key (- /) to move to the next
