ADR233B
option.
PORT 1
Ethernet Mode
FIXED
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Ethernet Mode can be set i.e. FIXED /
DUAL
Press the Minus / Down arrow key (- /) to move to the next
option.
PORT 1
Operating Mode
Fail Over
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Operating Mode can be set i.e. Fail
Over / Switch Mode.
Press the Minus / Down arrow key (- /) to move to the next
option.
PORT 1
Primary
LAN 1
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Primary can be set i.e. LAN1 / LAN 2.
Press the Right arrow key () to move to the next option.
For PRP/HSR Model
PORT 1
Ethernet Mode
DUAL
Read-only
This window shows the Ethernet Mode DUAL
Press the Minus / Down arrow key (- /) to move to the next
option.
For PRP/HSR Model
PORT 1
Operating Mode
PRP
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Operating Mode can be set i.e. PRP/
HSR.
Press the Minus / Down arrow key (- /) to move to the next
option.
For PRP/HSR Model
PORT 1
Primary
LAN 1
Read Only
This window shows the Primary LAN1.
Press the Right arrow key () to move to the next option.
