Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 268 of 479
ADR233B
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
MEASURMENTS
GLOBAL

CB CONTOL
REPORTING
8.4.4.4 PORT F
MEASURMENTS
GLOBAL

CB CONTOL
REPORTING
Password protected window for “Global” setting. i.e. General
Settings, Setting Group, Port F, Port 1, PORT R , IRIG Port,
Disturbance, Display Contrast and Date and Time.
Press the Right arrow key () to move to the next option.
General Settings
Settings Group
PORT F

PORT 1
Read-only setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Port F.
This window to view “PORT F” setting i.e. Unit ID, Baud Rate
and Parity.
Press the Right arrow key () to move to the next option.
PORT F
Unit ID
1
Read-only setting
This window shows the Unit ID of the relay.
Press the Minus / Down arrow key (- /) to move to the next
option.
PORT F
Baud Rate
57600 BPS
Read-only setting
This window shows the Baud Rate of the relay.
Press the Minus / Down arrow key (- /) to move to the next
option.
PORT F
Set Parity
None
Read-only setting
This window shows the Set Parity of the relay.
Press the Right arrow key () to move to the Main Menu.
