Ashida ADR233B - Page 269

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 269 of 479
ADR233B
MEASURMENTS
GLOBAL

CB CONTOL
REPORTING
8.4.4.5 PORT 1
MEASURMENTS
GLOBAL

CB CONTOL
REPORTING
Password protected window for “Global” setting. i.e. General
Settings, Setting Group, Port F, Port 1, PORT R , IRIG Port,
Disturbance, Display Contrast and Date and Time.
Press the Right arrow key () to move to the next option.
General Settings
Settings Group
PORT F
PORT 1

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select PORT 1.
Password protected window for “PORT 1” setting i.e. Unit ID,
IP Address, Subnet Mask, Default Gateway, Pri. SNTP, Sec.
SNTP, Protocol, Ethernet Mode, Operating Mode and Primary
Press the Right arrow key () to move to the next option.
PORT 1
Unit ID
1
Range 1 – 247
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Unit ID address can be set. The setting
range is from 001 to 247 in step of 001, which means total
247 devices can be connected to single computer. These
settings are required to communicate with the SCADA
computer.
Press the Minus / Down arrow key (- /) to move to the next
option.
PORT 1
IP address =
192.168.001.100
Range 0 – 255
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IP Address can be set in each of the
decimal section. The setting range is from 0 to 255. As per
Editing Password setting.
Press the Minus / Down arrow key (- /) to move to the next
option.
