PORT F
PORT 1
PORT R
IRIG Port

Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select IRIG Port.
Press the Right arrow key () to move to the next option.
IRIG Port
IRIG Port
Disabled
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IRIG Port can be set i.e. Enabled /
Disabled.
Press the Right arrow key () to move to the next option.
MEASURMENTS
GLOBAL

CB CONTOL
REPORTING
8.4.4.8 DISTURBANCE
MEASURMENTS
GLOBAL

CB CONTOL
REPORTING
Password protected window for “Global” setting. i.e. General
Settings, Setting Group, Port F, Port 1, PORT R , IRIG Port,
Disturbance, Display Contrast and Date and Time.
Press the Right arrow key () to move to the next option.
PORT 1
PORT R
IRIG Port
Disturbance

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Disturbance.
Password protected window for “Disturbance” setting i.e.
Post Trigger and Sampling.
Press the Right arrow key () to move to the next option.
Disturbance
Post Trigger
95 %
Range 5 – 95%
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Post Trigger can be set.
The setting range is from 5% to 95% in step of 1%.
Press the Minus / Down arrow key (- /) to move to the next
option.
