9.11.11 Breaker Failure
9.11.11.1 W1 50 BF (If Disabled)
SAVE Settings
DISCARD Settings
4
Target Reset
3
Press 3 Key
For Save
Press Target Reset
Key For Cancel
W1 50 BF
W1 50BF Enable
Disabled
6 5
Under Voltage
Over Voltage
V/Hz Protection
Breaker Failure
4
6
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1
4
Breaker Failure
W1 50 BF
4
W2 50 BF
6 5
Note: The 50 BF settings of W2 50 BF is similar to W1 50 BF settings.
