ADR233B
IB – Bias :
0.00 pu
IB – Diff :
0.00 pu
This window will show Bias & Diff Current of Phase B
Press the Minus / Down arrow key (- /) to move to the next
option.
IC – Bias :
0.00 pu
IC – Diff :
0.00 pu
This window will show Bias & Diff Current of Phase C
Press the Minus / Down arrow key (- /) to move to the next
option.
Iref :
0.00 pu
Iref Diff :
0.00 pu
This window will show High Impedance Iref current and Low
Impedance Iref Differential Current.
Press the Minus / Down arrow key (- /) to move to the next
option.
Iref Bias :
0.00 pu
This window will show Low Impedance Iref Bias current.
Press the Right arrow key () to move to the Main Menu
MEASURMENTS

GLOBAL
CB CONTOL
REPORTING
8.4.4 GLOBAL
8.4.4.1 Global Setting – Menu List
MEASURMENTS
GLOBAL

CB CONTOL
REPORTING
Editable Setting
Password protected window for “Global” setting i.e. General
Settings, Setting Group, Port F, Port 1, PORT R , IRIG Port,
Disturbance, Display Contrast & Date and Time.
Press the Right arrow key () to move to the next option.
