ADR233B
General Setting

Editable Setting
Password protected window for “General Settings” i.e.
Password, TID, SID, Phase, System Frequency, Opto I/P
Supply, W1 CB Operation, W2 CB Operation, PB-1
Operation, tPB-1 Pulse, PB-2 Operation, tPB-2 Pulse, Config
Port, Timesync Master, Description, Model Number, Serial
Number, Software Versi
on, Hardware Version and
Equipment.
Press the Minus / Down arrow key (- /) to move to the next
option.
Settings Group

Editable Setting
Password protected window for “Settings Group” i.e.
Factory Defaults, Active Group, Copy From, Copy To, G1, G2,
G3 and G4.
Press the Minus / Down arrow key (- /) to move to the next
option.
PORT F

Read-Only Setting
To View “PORT F” setting. i.e. Unit ID, Baud Rate and Set
Parity.
Press the Minus / Down arrow key (- /) to move to the next
option.
PORT 1

Editable Setting
Password protected window for “PORT 1” setting. i.e. Unit ID,
IP Address, Subnet Mask, Default Gateway, Pri. SNTP, Sec.
SNTP, Protocol, Ethernet Mode, Operating Mode and Primary
Press the Minus / Down arrow key (- /) to move to the next
option.
PORT R

Editable Setting
Password protected window for “PORT R” setting i.e. Unit ID,
Baud Rate and Set Parity.
Press the Minus / Down arrow key (- /) to move to the next
option.
