ADR233B
Ref ID : ADR233B/IM/SS
Rev No. : 05
Page No. : 166 of 479
9.
Operating Mode Fail over Fail over / Switch mode
This setting is used to set the Operating Mode of the IED
10.
Primary LAN 2 LAN1 / LAN 2
This setting is used to set primary communication of Ethernet Port in Fail Over Mode.
11.
Ethernet Mode* Dual Read only
This setting is used to set the Ethernet Mode.
12.
Operating Mode* PRP PRP / HSR
This setting is used to set the Operating Mode of the IED
13.
Primary* LAN 1 Read only
This setting is used to set primary communication of Ethernet Port.
Note: *Marked setting is available for PRP/HSR model only
6.1.5 PORT R
Sr. No Parameter Defaults setting Setting / Ranges
1.
Unit ID 001 1 to 247 in step of 1
This setting is to set the unique address for the relay such that only one relay is accessed by master
station software.
2.
Baud Rate 57600 9600 / 19200 / 38400 / 57600
This setting is to control communication speed between relay and master station. It is important that
both relay and master station are set at the same speed setting.
3.
Set Parity None None / Even / Odd
This setting is to control Rear Port parity format used in the data frames. It is important that both relay
and master station are set with the same parity setting.
6.1.6 IRIG Port (Optional)
Sr. No Parameter Defaults setting Setting / Ranges
1.
IRIG Port Disabled Disabled / Enabled
This setting is to Enable IRIG-B communication of the IED
6.1.7 Disturbance
Sr. No Parameter Defaults setting Setting / Ranges
1.
Post Trigger 5% 5 to 95% in step of 1%
This setting is to set Pre-fault duration of disturbance recorder.
2.
Sampling 16 Samples 16 Samples / RAW Samples
The setting is to select samples of Disturbance Recorder.
