ADR233B
W1 CB CONTROL
t CB Open Pulse
0.50 s
Range 0.1 – 50s
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the t CB Open Pulse can be set.
The setting range is from 0.10s to 50s in step of 0.01s
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 CB CONTROL
t CB Close Pulse
0.50 s
Range 0.1 – 50s
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the t CB Close Pulse can be set.
The setting range is from 0.10s to 50s in step of 0.01s
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
MEASURMENTS
GLOBAL
CB CONTOL

REPORTING
Note : The CB CONTROL setting for W2 CB CONTORL is similar to W1 CB CONTORL.
8.4.6 To View – REPORTING
MEASURMENT
GLOBAL
CB CONTOL
REPORTING

This menu is to view “Reporting” i.e. Event, Status, Fault
Record, Error Log, CB Data and Alarm Record.
Press the Right arrow key () to move to the next option.
