Ashida ADR233B - Error Log; To View - Error Lof

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 292 of 479
ADR233B
W2 – Ic MAG
2.00043A
In MAG
1.99925 A
This window shows Fault Values of W2 secondary Current
Press the Minus / Down arrow key (- /) to move to the next
option.
W2 – I1 MAG
2.0028A
W2 – I2 MAG
0.1008 A
This window shows Fault Values of W2 secondary Current
Press the Minus / Down arrow key (- /) to move to the next
option.
W2 –3I0 MAG
0.00514A
V :
111.05337 A
This window shows Fault Values of W2 secondary Current
and voltage.
Press the Minus / Down arrow key (- /) to move to the next
option.
V/Hz
2.2210
Th State
0%
This window shows Fault value of V/Hz and Thermal State.
Press the Right arrow key () to move to the Main Menu.
MEASURMENT
GLOBAL
CB CONTOL
REPORTING

Note: Parameter and flags assigned for fault through Alias are available in the fault window
8.4.6.4 Error Log
8.4.6.4.1 To View – Error Lof
MEASURMENT
GLOBAL
CB CONTOL
REPORTING

This menu is to view “Reporting” i.e. Event, Status, Fault
Record, Error Log, CB Data and Alarm Record.
Press the Right arrow key () to move to the next option.
