Ashida ADR233B - Page 291

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 291 of 479
ADR233B
Protection Trip
TC : 1
Date: 01/04/20
Time: 10:10:10:948
This window shows Type of fault, the Trip Counter, Date and
time of the Fault.
Press the Minus / Down arrow key (- /) to move to the next
option.
General P
General T
W1 Seq>1 T
W2 Seq>1 T
This window shows Trip Flags
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 I1 T
W2 I1 T
This window shows Trip Flags
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 – Ia MAG
1.99992A
W1 – Ib MAG
2.00133 A
This window shows Fault Values of W1 secondary Current
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 – Ic MAG
2.00140A
W1 – I1 MAG
1.94008 A
This window shows Fault Values of W1 secondary Current
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 – I2 MAG
0.34504A
W1 –3I0 MAG
0.34504A
This window shows Fault Values of W1 secondary Current
Press the Minus / Down arrow key (- /) to move to the next
option.
W2 – Ia MAG
2.00620 A
W2 – Ib MAG
2.00190 A
This window shows Fault Values of W2 secondary Current
Press the Minus / Down arrow key (- /) to move to the next
option.
