9.4.1 General Settings
(*)
General Setting
Password
* * * *
General Setting
System Frequency
50Hz
General Settings
Description
ASHIDA ADR233B E0
Press 3 Key
For Save
Press Target Reset
Key For Cancel
SAVE Settings
Target Reset
3
3 4
General Settings
Serial Number
xxx233Bxxxx
4
General Settings
Software Version
233BE0xxxxxxxVx.xx
General Setting
Hardware Version
Vx.xx
General Settings
Timesync Master
PORT F
EDIT
General Settings
4
Settings Group
PORT F
PORT 1
4
MEASUREMENT
GLOBAL
4
CB CONTROL
REPORTING
6 5
3 4
3 4
3 4
DISCARD Settings
General Settings
TID
Transformer_ID
General Setting
SID
SubStn_ID
General Settings
Phase Ref.
PT
General Setting
Opto I/P Supply
DC
3 4
General Setting
W1 CB Operation
No Operation
3 4
General Setting
PB-1 Operation
Enabled
3 4
General Setting
tPB-1 Pulse
0.50 s
Range 0.1 – 50s
3 4
General Setting
PB-2 Operation
Enabled
3 4
General Setting
tPB-2 Pulse
0.50 s
Range 0.1 – 50s
3 4
General Setting
Config Port
PORT F
General Settings
Model Number
ADR233BE0xxxxxxxxxxS
General Setting
W2 CB Operation
No Operation
3 4
3 4
3 4
3 4
3 4
3 4
3 4
3 4
General Setting
Equipment
Transformer
3 4
General Setting
Virtual Scheme 1
Disabled
3 4
General Setting
Virtual Scheme 2
Disabled
3 4
