ADR233B
Ref ID : ADR233B/IM/SS
Rev No. : 05
Page No. : 171 of 479
2.
Clear Events No Yes / No
By selecting “Yes” it will cause the existing Events Stored to be erased from the relay.
3.
Clear Faults No Yes / No
By selecting “Yes” it will cause the existing Fault Records to be erased from the relay.
4.
Clear Disturbance No Yes / No
By selecting “Yes” it will cause the existing Disturbance Records to be erased from the relay.
5.
Clear Error Record No Yes / No
By selecting “Yes” it will cause the existing Maintenance Records to be erased from the relay.
6.
W1 CB Data No Yes / No
By selecting “Yes” it will cause the existing W1 CB records to be clear to zero.
7.
W2 CB Data No Yes / No
By selecting “Yes” it will cause the existing W2 CB records to be clear to zero.
8.
Thermal State No Yes / No
By selecting “Yes” it will cause the existing Thermal state reset to zero.
6.7 OUTPUT & LED TEST:
Sr. No Parameter Defaults setting Setting / Ranges
1. Password 0000 0000 to zzzz/ZZZZ
This setting is to enter the set password
2. Test Mode Disabled Disabled / Test Mode / Contacts
Blocked
This setting allows secondary injection testing to be performed on the relay itself.
3. Test Output J 00000000 0 = Not Operated, 1 = Operated
This setting is used to select the output relay contacts that will be tested when the Contact Test cell is set
to Apply Test.
4. Test Output K 00000000 0 = Not Operated, 1 = Operated
This setting is used to select the output relay contacts that will be tested when the Contact Test cell is set
to Apply Test.
5. Test Output L 00000000 0 = Not Operated, 1 = Operated
This setting is used to select the output relay contacts that will be tested when the Contact Test cell is set
to Apply Test.
6. Test Output M 00000000 0 = Not Operated, 1 = Operated
This setting is used to select the output relay contacts that will be tested when the Contact Test cell is set
to Apply Test.
7. Test Apply No Operation No Operation/Apply Test/Remove
Test
This setting is used to Test contact operation of relay output.
8. Test LEDs No Operation No Operation / Apply Test
This setting is used to Test the 16 no’s programmable LED’s.
