ADR233B
TC = 0
W2–BOT = 0 mSec
W2–BOC = 0
This window shows Tripping counter, Breaker Opening Time
and Breaker Operation Counter
Press the Right arrow key () to move to the Main Menu.
MEASURMENT
GLOBAL
CB CONTOL
REPORTING

8.4.6.6 Alarm Record
8.4.6.6.1 To View – Alarm Record
MEASURMENT
GLOBAL
CB CONTOL
REPORTING

This menu is to view “Reporting” i.e. Event, Status, Fault
Record, Error Log, CB Data and Alarm Record.
Press the Right arrow key () to move to the next option.
Alarm Record

By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select “Alarm Record”
Press the Right arrow key () to move to the next option.
W1 TCS Alarm
This window shows W1 TCS Alarm
Press the Right arrow key () to move to the next option.
13/04/2018
06:14:50:900
This window shows Tripping counter, Breaker Opening Time
and Breaker Operation Counter
Press the Right arrow key () to move to the Main Menu.
