8.4.11.7.2 W1 Residual OC (If IEC Curve is selected)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
REF
Phase OC
Ground OC
Residual OC

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Residual OC.
Press the Right arrow key () to move to the next option.
Residual OC
W1 Residual OC

W2 Residual OC
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select W1 Residual OC.
Password protected window for “W1 Residual OC” setting
i.e. 3Io>1 Enable, 3Io>2 Enable and 3Io>3 Enable can be set
as Disabled/Enabled.
Press the Right arrow key () to move to the next option.
W1 Residual OC
3Io>1 Enable
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 3Io>1 Enable can be set i.e. Disabled /
Enabled.
Note: When set as Enabled.
Press the Right arrow key () to move to the next option.
