Ashida ADR233B - Page 346

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 346 of 479
ADR233B
i.e. 3Io>1 Enable, 3Io>2 Enable and 3Io>3 Enable can be set
as Disabled/Enabled.
Press the Right arrow key () to move to the next option.
W1 Residual OC
3Io>1 Enable
Disabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 3Io>1 Enable can be set i.e. Disabled /
Enabled.
Note: When set as Disabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Residual OC
3Io>2 Enable
Disabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 3Io>2 Enable can be set i.e. Disabled /
Enabled.
Note: When set as Disabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Residual OC
3Io>3 Enable
Disabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 3Io>3 Enable can be set i.e. Disabled /
Enabled.
Note: When set as Disabled.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
