Ashida ADR233B - CB Control - W1 CB CONTROL (if Enabled)

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 283 of 479
ADR233B
W1 CB CONTROL
m constant
1
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the m constant can be set.
The setting range is from 0.1 to 5 in step of 0.001.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 CB CONTROL
CB Control by
Disabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the CB Control By can be set i.e. Disabled /
Local / Remote / Local + Remote.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
MEASURMENTS
GLOBAL
CB CONTOL

REPORTING
Note : The CB CONTROL setting for W2 CB CONTORL is similar to W1 CB CONTORL.
8.4.5.2 CB Control – W1 CB CONTROL (If Enabled)
MEASURMENTS
GLOBAL
CB CONTOL

REPORTING
Password protected window for “CB Control” setting i.e. W1
CB CONTROL and W2 CB CONTROL.
Press the Right arrow key () to move to the next option.
