Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 282 of 479
ADR233B
W1 CB CONTROL

W2 CB CONTROL
Password protected window for “W1 CB Control” setting i.e.
TCS Enable Disabled/Enabled, TCS Delay, CB Open S’vision
Disabled/Enabled, CB Open Time, CB Open Alarm
Disabled/Enabled, CB Rated I, m constant, CB Oper. Counter,
CB Control By Disabled/Local/Remote/Local+Remote, t CB
Open Pulse & t CB Close Pulse.
Press the Right arrow key () to move to the next option.
W1 CB CONTROL
TCS Enable
Disabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the TCS Enable can be set i.e. Disabled /
Logic Low / Logic High.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 CB CONTROL
CB Open S’vision
Disabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the CB Open Supervision can be set i.e.
Disabled / Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 CB CONTROL
CB Open Alarm
Disabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the CB Open Alarm can be set i.e. Disabled /
Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 CB CONTROL
CB Rated I
100 A
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the CB Rated I can be set.
The setting range is from 1 to 5000 A instep of 1A.
Press the Right arrow key () to move to the next option.
