ACTIVE GROUP

This menu is to view Active Group. i.e. G1, G2, G3 and G4.
8.4.3 MEASUREMENTS
8.4.3.1 To View – Measurement 1
MEASURMENTS

GLOBAL
CB CONTOL
REPORTING
This menu is to view MEASUREMENTS i.e. Measurement 1
and Measurement 2.
Press the Right arrow key () to move to the next option.
Measurement 1

Measurement 2
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Measurement 1. (This menu is to
view Measurement 1).
Press the Right arrow key () to move to the next option.
W1 – IA MAG :
0 A
W1 – IB MAG :
0 A
This window shows Primary Current in Phase A & Phase B of
Winding 1 (W1).
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 – IC MAG :
0 A
W1 – IAB MAG :
0 A
This window shows Primary Current in Phase C & Primary
Phase to Phase Current in AB of Winding 1 (W1).
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 – IBC MAG :
0 A
W1 – ICA MAG :
0 A
This window shows Primary Phase to Phase Current in BC &
CA of Winding 1 (W1).
Press the Minus / Down arrow key (- /) to move to the next
option.
