Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 248 of 479
ADR233B
SYSTEM CONFIG

Password protected window for “System Config” setting i.e.
CT/VT Ratio.
Press the Minus / Down arrow key (- /) to move to the next
option.
PROTECTIONS

Password protected window for “Protections” setting. i.e.
Equipment Data Disabled/Enabled,
Ph Differential
Disabled/Enabled, REF Disabled/Enabled, W1 Phase OC
Disabled/ Enabled, W2 Phase OC Disabled/Enabled, Ground
OC Disabled/Enabled, W1 Residual OC Disabled/Enabled,
W2 Residual OC Disabled/Enabled, W1 SEQ OC
Disabled/Enabled, W2 SEQ OC Disabled/Enabled, Under
voltage Disabled/Enabled, Overvoltage Disabled/ Enabled,
V/Hz Protection Disabled/Enabled, W1 50BF
Disabled/Enabled, W2 50BF Disabled/Enabled, Thermal
Overload Disabled/Enabled and Through Fault
Disabled/Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
CLEAR RECORDS

Password protected window for “Clear Records” setting i.e.
Events Yes/No, Faults Yes/No, Disturbance Yes/No, Error
Record Yes/No, W1 CB Data Yes/No, W2 CB Data Yes/No,
Thermal State Yes/No.
Press the Minus / Down arrow key (- /) to move to the next
option.
OUTPUT & LED TEST

Password protected window for “Output & LED Test”
setting. i.e. Test Mode, Test Output B1, Test Output B2, Test
Output B3, Test Output B4, Test Apply and Test LED.
Press the Minus / Down arrow key (- /) to move to the next
option.
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC (W1 Phase
OC, W2 Phase OC), Ground OC, Residual OC (W1 Residual
OC, W2 Residual OC) , Sequence OC (W1 Sequence OC,
W2 Sequence OC), Under Voltage, Over Voltage, V/Hz
Protection, Breaker Failure (W1 50BF, W2 50BF), Thermal
