ADR233B
Ref ID : ADR233B/IM/SS
Rev No. : 05
Page No. : 181 of 479
which an alarm will be generated.
5. T 20 1.0 to 200.0 min in step of 1 min
This setting shows the thermal time constant for a single time constant characteristic.
6. Service Factor 1.05 1 to 1.50 in step of 0.01
This setting specifies the Service Factor const of thermal over load function.
6.8.13 Through Fault
Sr. No Parameter Defaults setting Setting / Ranges
1. Password 0000 0000 to zzzz/ZZZZ
This setting specifies to enter the set password.
2. Through Fault Disabled Enabled or Disabled
This setting is to Enable or disable monitoring of through faults
3. TF Monitoring W1 W1 / W2 / Bias
This setting is to selects the input winding to be monitored to generate through fault alarm.
4. TF I> Trigger 1.00 pu 0.08 pu to 20.0 pu in step of 0.01
This setting Defines that a through fault event is recorded if any of the phase currents is larger than this
setting then it should raise the alarm
6.9 ACTIVE GROUP
Sr. No Parameter Defaults setting Setting / Ranges
1. Active Group Group1 Read only
This setting display the active group G1 is default setting.
