8.4.2 Main Menu List
MEASUREMENTS

GLOBAL
CB CONTROL
REPORTING
SYSTEM CONFIG
PROTECTIONS
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1
GROUP 2
GROUP 3
GROUP 4
ACTIVE GROUP
MEASUREMENTS, GLOBAL, CB CONTROL, REPORTING,
SYSTEM CONFIG, PROTECTIONS, CLEAR RECORDS,
OUTPUT & LED TEST, GROUP 1, GROUP 2, GROUP 3,
GROUP 4 and ACTIVE GROUP.
Since the LCD Display consist only of 4 Lines, the Main Menu
and their respective Sub Menu list can be scrolled up or down
by using the Up Arrow key () or the Down Arrow key ().
The arrow pointer suggests that particular Main Menu is
selected.
8.4.2.1 Main Menu List Details
MEASUREMENTS

This menu is to view Measurements i.e. Measurement 1 and
Measurement 2.
Press the Minus / Down arrow key (- /) to move to the next
option.
GLOBAL

Password protected window for “Global” setting. i.e. General
Settings, Settings Group, Port F, Port 1, PORT R , IRIG Port,
Disturbance, Display Contrast & Date and Time.
Press the Minus / Down arrow key (- /) to move to the next
option.
CB CONTROL

Password protected window for “CB Control” setting i.e. W1
CB CONTROL and W2 CB CONTROL.
Press the Minus / Down arrow key (- /) to move to the next
option.
REPORTING

This menu is to view “Reporting” i.e. Event, Status, Fault
Record, Error Log, CB Data and Alarm Record.
Press the Minus / Down arrow key (- /) to move to the next
option.
