Ashida ADR233B - Protections

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 298 of 479
ADR233B
GLOBAL
CB CONTOL
REPORTING
SYSTEM CONFIG

8.4.8 PROTECTIONS
CB CONTOL
REPORTING
SYSTEM CONFIG
PROTECTIONS

Password protected window for “Protections” setting. i.e.
Equipment Data Disabled/Enabled, Ph Differential
Disabled/Enabled, REF Disabled/Enabled, W1 Phase OC
Disabled/ Enabled, W2 Phase OC Disabled/Enabled, Ground
OC Disabled/Enabled, W1 Residual OC Disabled/Enabled,
W2 Residual OC Disabled/Enabled, W1 SEQ OC
Disabled/Enabled, W2 SEQ OC Disabled/Enabled,
Undervoltage Disabled/Enabled, Overvoltage Disabled/
Enabled, V/Hz Protection Disabled/Enabled, W1 50BF
Disabled/Enabled, W2 50BF Disabled/Enabled, Thermal
Overload Disabled/Enabled and Through Fault
Disabled/Enabled.
Press the Right arrow key () to move to the next option.
PROTECTIONS
Equipment Data
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Equipment Data can be set i.e. Disabled
/ Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
PROTECTIONS
Ph Differential
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Ph Differential can be set i.e. Disabled /
Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
PROTECTIONS
REF
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the REF can be set i.e. Disabled / Enabled.
Press the Minus / Down arrow key (- /) to move to the next
