PROTECTIONS
W1 Phase OC
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W1 Phase OC can be set i.e. Disabled /
Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
PROTECTIONS
W2 Phase OC
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W2 Phase OC can be set i.e. Disabled /
Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
PROTECTIONS
Ground OC
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Ground OC can be set i.e. Disabled /
Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
PROTECTIONS
W1 Residual OC
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W1 Residual OC can be set i.e. Disabled
/ Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
PROTECTIONS
W2 Residual OC
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W2 Residual OC can be set i.e. Disabled
/ Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
