ADR233B
Breaker Failure
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Breaker Failure.
Password protected window for “Breaker Failure” setting i.e.
W1 50BF Enable and W2 50BF Enable can be set as
Disabled / Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
Thermal Overload
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Thermal Overload.
Password protected window for “Thermal Overload” setting
i.e. THOL Enable can be set as Disabled / W1 / W2
Press the Minus / Down arrow key (- /) to move to the next
option.
Through Fault
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Through Fault.
Password protected window for “Through Fault” setting i.e.
TF Enable can be set as Disabled / Enabled
Press the Minus / Down arrow key (- /) to move to the next
option.
PROTECTIONS
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

8.4.11.2 Equipment Data
PROTECTIONS
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
