Ashida ADR233B - Page 310

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 310 of 479
ADR233B
Equipment Data

Ph Differential
REF
Phase OC
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Equipment Data.
Password protected window for “Equipment Data” setting
i.e. W1 Connection, W1 Grounding, W1 Nominal Range, W1
Nominal, MVA Rating, W2 Vector Group, W2 Connection, W2
Grounding, W2 Nominal Range, W2 Nominal, W1 Match
Factor, W2 Match Factor and REF Match Factor.
Press the Right arrow key () to move to the next option.
Equipments Data
W1 Connection
Y–Wye
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W1 Connection can be set i.e. Y-Wye /
D-Delta.
Note: When set as Y-Wye.
Press the Minus / Down arrow key (- /) to move to the next
option.
Equipments Data
W1 Grounding
Grounded
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W1 Grounding can be set i.e. Grounded
/ Ungrounded
Press the Minus / Down arrow key (- /) to move to the next
option.
Equipments Data
W1 Nominal Range
KV
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W1 Nominal Range can be set i.e. KV /
V.
Press the Minus / Down arrow key (- /) to move to the next
option.
If W1 Nominal Range set as KV
Equipments Data
W1 Nominal
33.0 KV
Range 1 – 1000KV
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W1 Nominal can be set.
The setting range is from 1 to 1000 KV in step of 0.1KV.
Press the Minus / Down arrow key (- /) to move to the next
