Ashida ADR233B - Page 311

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 311 of 479
ADR233B
option.
If W1 Nominal Range set as V
Equipments Data
W1 Nominal
415 V
Range 100 – 1000V
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W1 Nominal can be set.
The setting range is from 100 to 1000 V in step of 1V.
Press the Minus / Down arrow key (- /) to move to the next
option.
Equipments Data
MVA Rating
10.0 MVA
Range 0.1 – 5000MVA
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the MVA Rating can be set.
The setting range is from 0.1 to 5000 MVA in step of 0.1.
Press the Minus / Down arrow key (- /) to move to the next
option.
Equipments Data
Vector Group
0
Range 0 – 11
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Vector Group can be set.
The setting range is from 0 to 11 in step of 1.
Press the Minus / Down arrow key (- /) to move to the next
option.
Equipments Data
W2 Connection
Y–Wye
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select W2 Connection.
Password protected window for “W2 Connection” setting i.e.
Y-Wye / D-Delta / Z–Zigzag.
Note: When set as Y-Wye.
Press the Minus / Down arrow key (- /) to move to the next
option.
Equipments Data
W2 Grounding
Grounded
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W2 Grounding can be set i.e. Grounded
/ Ungrounded
Press the Minus / Down arrow key (- /) to move to the next
