Ashida ADR233B - Page 312

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 312 of 479
ADR233B
option.
Equipments Data
W2 Nominal Range
KV
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W2 Nominal Range can be set i.e. KV /
V.
Press the Minus / Down arrow key (- /) to move to the next
option.
If W2 Nominal Range set as KV
Equipments Data
W2 Nominal
33.0 KV
Range 1 – 1000KV
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W2 Nominal can be set.
The setting range is from 1 to 1000 KV in step of 0.1KV.
Press the Minus / Down arrow key (- /) to move to the next
option.
If W2 Nominal Range set as V
Equipments Data
W2 Nominal
415 V
Range 100 – 1000V
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W2 Nominal can be set.
The setting range is from 100 to 1000 V in step of 1V.
Press the Minus / Down arrow key (- /) to move to the next
option.
Equipments Data
W1 Match Factor
1.000
Read-Only
This window shows the W1 Match Factor.
Press the Minus / Down arrow key (- /) to move to the next
option.
Equipments Data
W2 Match Factor
1.000
Read-Only
This window shows the W2 Match Factor.
Press the Minus / Down arrow key (- /) to move to the next
option.
Equipments Data
REF Match Factor
1.000
Read-Only
This window shows the REF Match Factor.
Press the Right arrow key () to move to the next option.
