8.4.11.11 V/Hz Protection
8.4.11.11.1 V/Hz Protection (If Disabled)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
Sequence OC
Under Voltage
Over Voltage
V/Hz Protection

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select V/Hz Protection.
Password protected window for “V/Hz Protection” setting i.e.
V/Hz – 1 Protection, V/Hz – 2 Protection, V/Hz – 3 Protection,
V/Hz – 4 Protection, V/Hz – 5 Protection, V/Hz – 6 Protection
and can be set as Disabled/Enabled
Press the Right arrow key () to move to the next option.
V/Hz Protection
V/Hz – 1 Protection

Disabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select V/Hz – 1 Protection.
Password protected window for “V/Hz – 1 Protection” setting
i.e. can be set as Disabled / Enabled.
Note: When set as Disabled.
Similarly if V/Hz – 2 Protection, V/Hz – 3 Protection, V/Hz
– 4 Protection, V/Hz – 5 Protection, V/Hz – 6 Protection
are set as Disabled.
Press the Right arrow key () to move to the next option.
