ADR233B
Residual OC
SEQUENCE OC
Under Voltage
Over Voltage

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Over Voltage.
Press the Right arrow key () to move to the next option.
Over Voltage
Over Voltage SET

Enabled
Editable Setting
Password protected window for “Over Voltage SET” can be
set i.e. Disabled / Enabled.
Note: When set as Enabled.
Press the Right arrow key () to move to the next option.
Over Voltage SET
V>
105%
Range 105% – 150%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the V> can be set.
The setting range is from 105% to 150% in step of 1%
Press the Minus / Down arrow key (- /) to move to the next
option.
Over Voltage SET
tV> Delay
0.1 s
Range 0 – 99s
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the tV> Delay can be set.
The setting range is from 0 to 99s in step of 0.1s.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
