ADR233B
J Out : 87654321
00000000
K Out : 87654321
00000000
This window shows actual status of Digital Output
Press the Right arrow key () to move to the Main Menu.
Applicable for Basic Relay
H In : 87654321
00000000
I In : 4321
0000
This window shows actual status of Digital Inputs
Press the Minus / Down arrow key (- /) to move to the next
option.
J Out : 87654321
00000000
K Out : 321
000
This window shows actual status of Digital Inputs
Press the Minus / Down arrow key (- /) to move to the next
option.
MEASURMENT
GLOBAL
CB CONTOL
REPORTING

8.4.6.3 Fault Record
8.4.6.3.1 To View – Fault Record
MEASURMENT
GLOBAL
CB CONTOL
REPORTING

This menu is to view “Reporting” i.e. Event, Status, Fault
Record, Error Log, CB Data and Alarm Record.
Press the Right arrow key () to move to the next option.
Fault Record

By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select “Fault Record”
Press the Right arrow key () to move to the next option.
Fault Num = 01
This window shows Fault Record ( i.e. Fault Number 01 to 10)
Press the Right arrow key () to move to the next option.
