ADR233B
Ref ID : ADR233B/IM/SS
Rev No. : 05
Page No. : 169 of 479
5. CB Data Display of Trip Counter; Breaker Operation Counter; Breaker operating
time, Recl Cnt
6. Alarm Record Display of latest Alarm Record
6.4 SYSTEM CONFIG
6.4.1 CT/VT RATIOS
Sr. No Parameter Defaults setting Setting / Ranges
1.
Password 0000 0000 to zzzz/ZZZZ
This setting is to enter the set password
2.
W1 PH CT Secondary 1 A 1 A/5 A
This setting is to set the W1 Phase CT secondary.
3.
W1 PH CT Primary 10 A 10 to 5000 A in step of 1A
This setting is to set the W1 Phase CT Primary.
4.
W2 PH CT Secondary 1 A 1 A/5 A
This setting is to set the W2 Phase CT secondary.
5.
W2 PH CT Primary 10 A 10 to 5000 A in step of 1A
This setting is to set the W2 Phase CT Primary.
6.
EF CT Secondary 1 A 1 A/5 A
This setting is to set the Earth Fault CT secondary.
7.
EF CT Primary 10 A 10 to 5000 A in step of 1A
This setting is to set the Earth Fault CT Primary.
8.
CT Star Point Towards Object Towards Object / Away From Object
This setting is to set the connection of object
9.
VT Primary 1 kV 0.1 to 800 KV in step of 0.01kV L-L
This setting is to set the VT Primary.
10.
VT Selection Line to Line Read only setting
11.
VT Secondary 110V 110V / 120V
This setting is to set the VT Secondary
12.
Settings Values Secondary Primary / Secondary
This setting is to set the setting parameter in Primary or secondary
6.5 PROTECTIONS settings
Sr. No Parameter Defaults setting Setting / Ranges
1.
Password 0000 0000 to zzzz/ZZZZ
This setting is to enter the set password
2.
Equipment Data Enabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the Equipment Data function.
3.
Ph Differential Enabled Disabled / Enabled
