This setting is to enable (activate) or disable (turn off) the Phase Differential Protection function.
4.
REF Enabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the REF Protection function.
5.
W1 Phase OC Enabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the W1 Phase Over current Protection function. If
this function is enabled then all associated settings and signals are available in the Group setting menu.
6.
W2 Phase OC Enabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the W2 Phase Over current Protection function. If
this function is enabled then all associated settings and signals are available in the Group setting menu.
7.
Ground OC Enabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the Measured Earth Fault Protection function
8.
W1 Residual OC Disabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the W1 Derived Earth Fault Protection function.
9.
W2 Residual OC Disabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the W2 Derived Earth Fault Protection function.
10.
W1 Sequence OC Disabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the W1 Sequence OC Protection.
11.
W2 Sequence OC Disabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the W2 Sequence OC Protection.
12.
Under Voltage Disabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the under voltage function.
13.
Over Voltage Disabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the Over voltage function.
14.
V/Hz Protection Disabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the V/Hz function.
15.
W1 50BF Disabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the W1 Breaker failure function.
16.
W2 50BF Disabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the W2 Breaker failure function.
17.
Thermal Overload Disabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the Thermal Overload function.
18.
Through Fault Disabled Disabled / Enabled
This setting is to enable (activate) or disable (turn off) the Through Fault function.
6.6 CLEAR RECORDS settings:
Sr. No Parameter Defaults setting Setting / Ranges
1. Password 0000 0000 to zzzz/ZZZZ
This setting is to enter the set password
