ADR233B
Disturbance
Sampling
16 Samples
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Sampling can be set i.e. 16 samples /
RAW Samples.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
MEASURMENTS
GLOBAL

CB CONTOL
REPORTING
8.4.4.9 Display Contrast (Read Only)
MEASURMENTS
GLOBAL

CB CONTOL
REPORTING
Password protected window for “Global” setting. i.e. General
Settings, Setting Group, Port F, Port 1, PORT R , IRIG Port,
Disturbance, Display Contrast and Date and Time.
Press the Right arrow key () to move to the next option.
PORT R
IRIG Port
Disturbance
Display Contrast

Read-only setting
This window shows the Display Contrast.
Press the Right arrow key () to move to the next option.
Display contrast
Contrast Set
50 %
Read-only setting
This window shows the Contrast of the relay.
Press the Right arrow key () to move to the Main Menu.
