ADR233B
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTIONS
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

8.4.11.3 Ph Differential
8.4.11.3.1 Ph Differential (If Disabled)
PROTECTIONS
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
Equipment Data
Ph Differential

REF
Phase OC
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Ph Differential.
Password protected window for “Ph Differential” setting i.e.
Ph Differential Disabled/Enabled, Hrm BLK Criteria Disabled/
Enabled and 5th Hrm Diff BLK Disabled Enabled.
Press the Right arrow key () to move to the next option.
Ph Differential
Ph Differential
Disabled
Editable Setting
Password protected window for “Ph Differential” setting i.e.
Disabled / Enabled.
Press the Minus / Down arrow key (- /) to move to the next
