ADR233B
• “TARGET RESET”: Feather Touch Key ‘TARGET RESET’ is used to clear the fault LED
indications, clear the Alarms and ‘RESET’ the Relay Contacts. To CANCEL the changes
done in setting.
• “
” Feather Touch Key ‘PB1 operation’ to operate assigned respective Output locally by
pressing this key.
• “” Feather Touch Key ‘PB2 operation’ to operate assigned respective Output locally by
pressing this key.
• “EDIT”: Feather Touch Key “EDIT” is used to activate the settings to be modified (i.e. To
bring the cursor).
•
“()” Left Arrow: Feather Touch Left arrow Key () is used for navigating through and
submenus & to SAVE the changes done in setting.
•
“(+ / )” Plus / Up Arrow: Feather Touch Key Plus (+) is used to increment the setting value
in the display. The UP Arrow () is used to scroll the menu in up direction.
•
“(- / )” Minus / Down Arrow: Feather Touch Key Minus (-) is used to decrement the setting
value in the display. The () DOWN Arrow is used to scroll the menu in down direction.
•
“()” Right Arrow: Feather Touch key Right Arrow () is used to VIEW the settings and to
navigate through the menus and submenus.
Note: At the time of setting if changes are not carried within 100s then the display will reset itself and
return to the main menu.
8.2.3 LEDS
The ADR233B relay provides 16 nos. of dual color LED’s for indication. The following table explains the
assignment process to LED. Here G represents Green LED and R Represent Red LED.
Sr. No. Legend Description
1
L1
Programmable Dual Colour LED
Default Assignment: GREEN LED – indicates Relay Enabled.
Default Assignment: RED LED – indicates Relay Error.
2 L2 User Programmable Dual Colour LED.
3 L3 User Programmable Dual Colour LED.
4 L4 User Programmable Dual Colour LED.
5 L5 User Programmable Dual Colour LED.
6 L6 User Programmable Dual Colour LED.
7 L7 User Programmable Dual Colour LED.
8 L8 User Programmable Dual Colour LED.
