SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Note: The setting for TF monitoring i.e. W2 and Bias is similar to W1 Settings.
8.4.12 Active Group
8.4.12.1 To View – Active Group
ACTIVE GROUP

MEASURMENT
GLOBAL
CB CONTOL
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Active Group.
This menu is to view ACTIVE GROUP. i.e. G1, G2, G3 and
G4.
Press the Right arrow key () to move to the next option.
Active Group
G1 – G4
Group1
This window shows the Active Group. i.e. G1
Press the Right arrow key () to move to the Main Menu
ACTIVE GROUP

MEASURMENT
GLOBAL
CB CONTOL
